OD46L02
Description
The OD46L02 is a 46″ widescreen IP65 industrial monitor designed for digital signage and information display outdoors.
The 46″ LCD panel provides 1920 x 1080 (FullHD) resolution and 1500cd/m2 brightness for daylight viewing.
With a built in air conditioner, operation is possible at temperatures between -40oC and +55oC.
Features
46″ IP65 Outdoor Monitor
Native Resolution 1920×1080 @60Hz
1500cd/m2 Brightness
DVI and VGA input
Optional Touch Screen
Operating Temp of -40oC to +55oC
LED backlight
Vandal Proof Chassis
Suitable for:
Advertising Boards
Interactive Maps
Description
|
Screen Size
|
46″, 1920 x 1080 resolution
|
|
Display Colours
|
16.7M
|
|
Brightness
|
Typ. 1500cd/m2
|
|
Contrast Ratio
|
Typ. 3000:1
|
|
Backlight Lifetime
|
Typ. 100,000 hours
|
|
Viewing Angle
|
Horizontal: Typ. 89°/89°, Vertical: Typ. 89°/89°
|
|
Backlight Type
|
Edge LED
|
|
Protection
|
IP65 chassis, vandal proof glass, anti-corrosion
|
|
Temperature control
|
Built-in air conditioner/heater
|
|
Power Input
|
AC 108V-240V
|
|
Dimension
|
1090 x 642 x 330 mm
|
I/O Ports
|
Digital
|
DVI/HDMI
|
|
Analogue
|
VGA
|
|
Optional Inputs
|
S-Video and Composite video
|
Optional Touch Screen
|
Touch Sensor Type
|
IR
|
|
Touch Controller Type
|
USB
|
Environment
|
Temperature
|
Operating: -45 to 55°C
|
Additional information
| Mount Type | VESA Arm Mount |
|---|---|
| Monitor Type | Waterproof/Outdoor |
| Screen Size | 46" |
| Operating Temperature | -45°C to 55°C |
| Brightness | 1500cd/m² |
| Inputs | DVI, HDMI, VGA |
| Viewing Angle | 89° / 89° |
| Touch Type | Infrared |
| IP Rating | IP65 |
