PA-6222
Description
The PA-6222 is a low power point of sale terminal built using the latest Intel J1900 quad core CPU and can be desktop mounted. The built-in 12″ LCD panel provides 1024 x 768 (XGA) resolution, plus optional second 8″/10″ display, and the 5-wire resistive touch sensor provides precise control.
The five USB ports and three COM ports are among the many I/O ports available on this POS terminal, and expansion is possible with cash drawer, i-Button and MSR options.
Features
12″ Low Power Point of Sale Terminal
Support Celeron J1900 (2.42GHz)
Aluminum Die Casting Backcover
Fanless
5 wire resistive touchscreen
Support up to 8GB of RAM
Optional integrated Wireless LAN
Optional Fingerprint Reader and MSR
Downloads:
Description
|
CPU Type
|
Intel J1900 (rPGA988)
|
|
Memory Support
|
1pcs x DDR-3L SO-DIMM socket (up to 8GB)
|
|
Chipset Type
|
n/a
|
|
Power Supply
|
AC 100-240V 120W external power supply
|
|
O/S Support
|
Win 8 / 7 / POSReady7
|
|
Dimension
|
360 x 261 x 58mm
|
|
Basic System Weight
|
3.5kg
|
|
Certificate
|
CE / FCC
|
I/O Ports
|
Drive Bays
|
1 x 2.5″ HDD/SSD
|
|
USB
|
5 x USB 2.0
|
|
Serial Ports
|
3 x RJ-45
|
|
LAN
|
1 x 10/100/1000Mbps
|
|
Audio
|
Line-out, built-in 2W speaker
|
|
Expansion
|
RJ-11 cash drawer port
|
|
VGA
|
1 x 15-pin VGA
|
|
LCD
|
12″ XGA TFT LCD
|
|
Touch Screen
|
Bezel-Free 5 wire analogue resistive
|
|
Brightness
|
500cd/m²
|
|
Display Tilt Angle
|
n/a
|
|
Option
|
i-Button, MSR, VFD, Customer Display, Fingerprint Reader
|
Environment
|
Temperature
|
Operating: 0 to 35°C, Storage: -5 to 60°C
|
|
Humidity
|
20 to 90%
|
Additional information
| Fanless | Yes |
|---|---|
| Core | Intel, Intel Celeron |
| Mount Type | Desktop, VESA Mount |
| Operating System (OS) | POS Ready7, Windows 8 |
| Operating Temperature | 0°C to 35°C |
| Screen Size | 12" |
| IP Rating | IP65 Front Side (Only) |
