Product Description
|
CPU Type
|
Intel Atom N2930 (1.83GHz)
|
|
Memory Support
|
1pcs x DDR-3L SO-DIMM socket (up to 4GB)
|
|
Storage
|
3Gb mSATA, up to 128GB SSD
|
|
Battery Type
|
27.82Wh Li-ion Battery Pack, Hot Swappable (Needs 2nd Battery)
|
|
Power Supply
|
DC 19V with external power supply
|
|
O/S Support
|
Win 8.1, and Win 7
|
|
Dimension
|
275 x 198 x 28mm (without bumpers)
|
|
Basic System Weight
|
1.3kg (with standard battery pack)
|
|
Certificate
|
CE / FCC / cUL
|
I/O Ports
|
Cradle Connector
|
1 x Dock Connector
|
|
USB
|
1 x USB 3.0, 3 x USB 2.0
|
|
Serial Ports
|
1 x RS232
|
|
LAN
|
1 x 10/100/1000Mbps
|
|
Audio
|
Line-out and Mic
|
|
VGA
|
1 x 15-pin VGA
|
|
Expansion
|
1 x SIM card and 1 x SD/MMC/MS card slots
|
|
Wireless
|
802.11 b/g/n WLAN + HSUPA/E-GPRS/GPS WWAN
|
|
Bluetooth
|
Bluetooth 4.0 class II
|
|
Camera
|
Front: 2 Mega Pixel, Rear: 2 Mega Pixels (5 MP option)
|
|
Option Device Bay
|
Smart Card and RFID Combo drive or 2nd battery
|
|
LCD
|
10″ XGA TFT LCD (sunlight readable option)
|
|
Touch Screen
|
Analogue resistive
|
|
Buttons
|
Power button, F1, F2, F3, F4, F5, F6, F7, F8 (Function Keys: Brightness, Volume, Screen rotation etc.)
|
|
Optional Dock Connectors
|
2 x USB, 1 x Ethernet, 1 x RS232, 1 x Power-in Jack, 1 x VGA, Supports VESA mount
|
Environment
|
Temperature
|
Operating: -20 to 50°C, Storage: -40 to 80°C
|
|
Cold Boot Temperature
|
0°C with battery at >75% charge
|
