SF-END21RF
Description
The SF-END21RF is a Full HD widescreen panel PC that can provide great performance due to the Intel Celeron J1900 CPU. The chassis is made from anti-corrosion galvanised steel.
The Gigabit LAN and 4 USB2.0 ports are among the many I/O ports available on this panel PC and power options are available for AC and DC supplies.
Features
21.5″ Slimline Panel PC
Support Intel Celeron J1900 (2.0GHz)
Gigabit LAN
Support DC 12V Power
Support up to 8GB of RAM
Optional Wifi
IP65 Rated Front Side
Suitable for:
Factory Control
Military Devices
Description
|
CPU Type
|
Intel Celeron J1900 (2.0GHz)
|
|
Memory Support
|
2pcs x DDR-3L SODIMM socket (up to 8GB)
|
|
Chassis
|
Anti-corrosion Galvanised Steel Chassis
|
|
Ruggedness Certification
|
IP65 Front Side
|
|
Power Supply
|
DC 12V with external adapter
|
|
O/S Support
|
Win 7Pro / 7e / 8Pro / 8e
|
|
Mounting Method
|
VESA-100 Mount
|
|
Dimension
|
578 x 372 x 73.7mm
|
|
Conformity Certification
|
CE / FCC
|
I/O Ports
|
Drive Bays
|
1 x 2.5″ HDD/SSD
|
|
USB
|
4 x USB 2.0
|
|
Serial Ports
|
1 x 9-pin (RS232)
|
|
LAN
|
1 x Gigabit, Optional WiFi
|
|
Digital I/O
|
n/a
|
|
VGA
|
15-pin for Secondary Display
|
|
DVI
|
n/a
|
|
Audio
|
Line-out, Mic-in
|
LCD
|
LCD Size
|
21.5″
|
|
LCD Resolution
|
1920 x 1080
|
|
Touch Screen
|
Optional 5-wire Analogue Resistive
|
Environment
|
Temperature
|
Operating: 0 to 45°C, Storage: -10 to 70°C
|
|
Humidity
|
10 to 90%
|
Additional information
| Screen Size | 21.5" |
|---|---|
| Core | Intel, Intel Celeron |
| Operating Temperature | 0°C to 45°C |
| Operating System (OS) | Windows 7, Windows 7 e, Windows 8, Windows 8 e, Windows 8.1 |
| Mount Type | VESA Mount |
| IP Rating | IP65 Front Side (Only) |
