SM-ZJD17RF
Description
The SM-ZJD17RF is a 17.3″ panel mount industrial monitor designed for industrial automation and monitoring. The 17.3″ LCD panel provides 1920 x 1080 (FullHD) resolution.
With the option of touch screen and VESA mount, the monitor can also be used as an interactive terminal.
Features
17.3″ Panel Mount Monitor
1920 x 1080 Resolution
VGA, DVI and optional HDMI inputs
Optional VESA arm mount
Optional Resistive touch screen
Backlight Lifetime: Typ 50,000 hours
Support DC 12V input
IP65 Front Bezel
Suitable for:
Factory Automation & Control
Downloads:
Description
|
Screen Size
|
17.3″, 1920 x 1080 resolution
|
|
Display Colours
|
16.7M
|
|
Viewing Angle
|
Horizontal: Typ. 85°/85°, Vertical: Typ. 70°/70°
|
|
Luminance
|
Typ. 400cd/m2
|
|
Backlight Lifetime
|
Typ. 50,000 hours
|
|
Contrast Ratio
|
Typ. 600:1
|
|
Mount Type
|
Panel mount and VESA100 arm mount
|
|
Power Input
|
DC 12V with external AC 100-240V Adapter
|
|
Dimension
|
TBD
|
|
Weight
|
8.5Kg
|
|
Chassis
|
Front – Aluminium, Rear – Steel
|
I/O Ports
|
Digital
|
DVI and optional HDMI
|
|
Analogue
|
15-pin VGA
|
Optional Touch Screen
|
Touch Sensor Type
|
5 wire resistive type
|
|
Touch Controller Type
|
USB or Serial options
|
Environment
|
Temperature
|
Operating: 0 to 5°C, Storage: -10°C to 70°C
|
Additional information
| Screen Size | 17.3" |
|---|---|
| Brightness | 400cd/m² |
| Viewing Angle | 160° / 140° |
| Mount Type | Panel Mount |
| Inputs | DVI, HDMI, VGA |
| Operating Temperature | 0°C to 45°C |
| Touch Type | Resistive |
| Monitor Type | Factory/Industrial |
