Product Description
|
CPU Type
|
Intel Celeron J1900 (2.0GHz) with SoC chipset
|
|
Memory Support
|
1pc x DDR-3L SO-DIMM socket (up to 8GB)
|
|
Front Bezel
|
Aluminium
|
|
Waterproof Level
|
IP65 front side
|
|
Power Supply
|
9-36V DC input, optional AC-DC power supply
|
|
O/S Support
|
Windows 7 Pro / 8.1
|
|
Dimension
|
408 x 308 x 70mm
|
|
Basic System Weight
|
6.5Kg
|
|
VESA support
|
75/100mm VESA bracket (optional)
|
|
Certificate
|
CE / FCC
|
I/O Ports
|
Drive Bays
|
1 x 2.5″ SATA HDD, 1 x CFast slot onboard
|
|
USB
|
1 x USB3.0 + 2 x USB2.0
|
|
Serial Ports
|
4 x 9-pin*, COM1/2 for RS232/422/485
|
|
LAN
|
2 x 10/100/1000Mbps with optional PoE (IEEE 802.3af, max 15.4W/port)
|
|
Wireless LAN
|
Optional 802.11b/g/n card or 3G Card
|
|
Audio
|
Line-out
|
|
Expansion
|
1 x fullsize mini-PCI-e for WiFi/3G, 1 x halfsize mini-PCI-e
|
|
DVI
|
1 x DVI-I
|
|
Digital I/O
|
n/a
|
LCD Display
|
LCD
|
15″ XGA TFT LCD
|
|
Touch Screen
|
5 wire analogue resistive (USB interface)
|
Environment
|
Temperature
|
Operating: 0 to 40°C, Storage: -30 to 60°C
|
|
Humidity
|
20 to 90%
|
